Allied Moulded Products - Allied Moulded Products 5305-NBK 3-9/16 x 9-1/4 x 3-3/4 Inch 94 In. 5-Gang Angled Mid-Nail Switch/Receptacle Outlet Box

CopyCopy
Allied Moulded Products - Allied Moulded Products 5305-NBK 3-9/16 x 9-1/4 x 3-3/4 Inch 94 In. 5-Gang Angled Mid-Nail Switch/Receptacle Outlet Box

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 085339180029

  • Applications - New work residential construction 2 HR fire resistive walls

  • Buy American - Y

  • Catalog Number - 5305-NBK

  • Color - White

Packaging

  • 1 ea

EAN

00085339180029

Part #

175987

Catalog #

5305-NBK

Commercial reference

5305-NBK

12-Digit UPC:

085339180029

Applications:

New work residential construction 2 HR fire resistive walls

Buy American:

Y

Catalog Number:

5305-NBK

Color:

White

Construction:

Injection Molded

Country of Origin:

USA

Depths:

3-9/16 Inch

ERP_productname:

ALLI 5305-NBK FBRGLS 5G SW BOX 94.0 CU IN ANGLED MID-NAILS ADJ STABILIZING BAR SPEED KLAMPS

Family Brand Name:

FiberglassBox

Heights:

3-3/4 Inch

Material:

Polyester

Mounting Type:

Angled Mid Nails With Adjustable Stabilizer Bar

Number of Gangs:

5 Gang

Size:

D=3 9/16", W=9 7/16", H=3 3/4"

Sub Brand:

FIBERGLASSBOX

Type:

Five Gang Electrical Box For Use With Nonmetallic Sheathed Cable

Widths:

9 5/16 in

SoneparProductId:

SKU_US_25386814

94.0 Cu. In. Five gang electrical box for use with nonmeatllic sheathed cable - Machine tapped device holes, offset gauge marks, leveling ribs, rigid hard box construction, no distortion with high temperatures, shatter resistant with low temperatures - New work residential construction 2 HR fire resistive walls - Fiberglass reinforced polyester - thermoset box with galvanized steel stabilizer bar - Size: D=3 9/16", W=9 7/16", H=3 3/4" - Mount with Angled mid nails with adjustable stabilizer bar Features: Machine tapped device holes; slot provision for low voltage divider; offset gauge marks; leveling ribs; rigid hard box construction; no distortion with high temperatures; shatter resistant with low temperatures; Speed .K. Clamps factory installed - Standards: ANSI / UL 514C - File No. E30594 - Application: New work residential construction 2 HR fire resistive walls - Fire Classification: ANSI / UL 263 - File No. CEYY.R9379; Fire Resistance Classification in Wall Assemblies 2-Hours or less - Shall be separated by a horizontal distance of not less than 24 inches - Manufacturer Notes: Products must also be certified to: ANSI / UL 514C; For more details please refer to the UL fire resistive directory and Allied Moulded.s CEYY.9379 (Outlet boxes and fittings classified for fire resistance)
