Appleton Electric - Sola Hevi-Duty SDP2-24-100T Low Power DIN Rail Power Supply. Output: 24Vdc, 2.1A

CopyCopy

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 783472151622

  • Amperage - 400/700 mA Input, 1.3 Amp Output

  • Applications - For Industrial Control, Process Control, Machine Control, Building Automation, Instrumentation

  • Catalog Number - SDP224100T

  • ERP_productname - HEVI SDP2-24-100T 50W 24V DIN PLACTIC 115/230VIN

Packaging

  • 1 ea

EAN

00783472151622

Part #

309658

Catalog #

SDP2-24-100T

Commercial reference

SDP2-24-100T

12-Digit UPC:

783472151622

Amperage:

400/700 mA Input, 1.3 Amp Output

Applications:

For Industrial Control, Process Control, Machine Control, Building Automation, Instrumentation

Catalog Number:

SDP224100T

ERP_productname:

HEVI SDP2-24-100T 50W 24V DIN PLACTIC 115/230VIN

Enclosure:

Class 1, IP20

Family Brand Name:

Emerson Electric Co.

Heights:

2.95 Inch

Input Voltage:

85 - 264 VAC, 90 - 375 VDC

Length:

1.77 Inch

Material:

Plastic

Mounting Type:

DIN Rail

Number of Phases:

1 Phase

Output Voltage:

24 - 28 VDC

Sub Brand:

SolaHD™

Type:

Low Power, Short-Circuit-Proof

Voltage:

264//375 VAC//VDC

Widths:

3.58 in

SoneparProductId:

SKU_US_25628154

SDP™ Low Power DIN Rail Series Power Supplies provide efficient power from 5 to 48 Vdc and up to 100 Watts in a choice of compact, lightweight DIN rail mounted units. These affordable power supplies offer the exceptional reliability and advanced features required for industrial use. PowerBoost™ overload circuitry starts up industrial loads that can cause ordinary power supplies to foldback or shutdown. Features: cULus, cRUus, CE, RoHS; Ultra slim 15W footprint; No tools required for mounting; Adjustable output; PowerBoost industrial overload design; Overvoltage, short circuit protection; Continuous short circuit protection; Low output noise; Screw terminal connections
