Cutler-Hammer / Eaton - Eaton DH224NRK Heavy Duty Safety Switch
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 782113206653
Amperage - 200 Amp
Catalog Number - DH224NRK
ERP_productname - CUT DH224NRK HDST, 200 A, NEMA 3R, 240 V, 2-POLE
Enclosure - 3R
Packaging
1 ea
EAN
00782113206653
Part #
281844
Catalog #
DH224NRK
Commercial reference
DH224NRK
12-Digit UPC:
782113206653
Amperage:
200 Amp
Catalog Number:
DH224NRK
ERP_productname:
CUT DH224NRK HDST, 200 A, NEMA 3R, 240 V, 2-POLE
Enclosure:
3R
Enclosure Material:
Steel
Family Brand Name:
Eaton
Heights:
6.14 Inch
Length:
27.6 Inch
Material:
Steel
NEMA Size:
3R
Number of Poles:
2 Pole
Number of Wires:
3 Wire
Type:
Heavy Duty Fusible Safety Switch
Voltage:
240 Volt
SoneparProductId:
SKU_US_57870230
Eaton Heavy duty single-throw fused safety switch, Enhanced visible blade, line/load labels, 2 blade, 200 A, NEMA 3R, Cartridge, Three-wire, 240 V, Max Hp: 15, 25 hp/15, 60 hp/40 hp (1,3PH @ Std fuse/time delay/250 Vdc), #6-250 kcmil Cu/Al
