Cutler-Hammer / Eaton - Eaton Electrical D3PF2AT1 24 VDC 470 Ohm DPDT Silver Alloy DC Operated General Purpose Plug-In Relay
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 782113720081
Applications - Automation And Logic Control Equipment
Catalog Number - D3PF2AT1
Coil Voltage - 24 V
ERP_productname - CUT D3PF2AT1 24V PLUG-IN RELAY
Packaging
1 ea
EAN
00782113720081
Part #
358489
Catalog #
D3PF2AT1
Commercial reference
D3PF2AT1
12-Digit UPC:
782113720081
Applications:
Automation And Logic Control Equipment
Catalog Number:
D3PF2AT1
Coil Voltage:
24 V
ERP_productname:
CUT D3PF2AT1 24V PLUG-IN RELAY
Enclosure:
IP40
Family Brand Name:
Eaton
Heights:
1.39 Inch
Length:
2.2 Inch
Max Voltage:
300 V
Type:
General-purpose Relay
SoneparProductId:
SKU_US_52048400
D3 Series General Purpose Plug-In Relay, Full featured cover, 8 pins, 24 Vdc coil, 470 Ohms resistance, Octal terminal, DPDT contact configuration, 16A contact rating, Silver alloy contacts, IP40 enclosure
