Ferraz Shawmut - Mersen 60608T 3-Pole 60 Amp 600 Volt Class T Fuse Block Box
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 782001675608
Amperage - 60 Amp
Catalog Number - 60608T
Class - T
Country of Origin - Mexico
Packaging
1 ea
EAN
00782001675608
Part #
151343
Catalog #
60608T
Commercial reference
60608T
12-Digit UPC:
782001675608
Amperage:
60 Amp
Catalog Number:
60608T
Class:
T
Country of Origin:
Mexico
ERP_productname:
FRZ 60608T 60A 600V FUSE BLOCK
Family Brand Name:
Ferraz Shawmut Canada, Inc.
Fuse Class:
Class T
Heights:
2.2 Inch
Length:
3.9 Inch
Mounting Type:
DIN Rail,Screw Mount
Number of Poles:
3 Pole
Rated Voltage AC:
600 V
Rated Voltage DC:
600 V
Tc Connection:
Box
Torque:
45 lb-in
Type:
Open-Style
Voltage:
600 Volt
Widths:
4.6 in
SoneparProductId:
SKU_US_59041160
Mersen Class T fuse blocks accommodate Class T fuses up to 600A. Insulators are either durable, glass-filled polycarbonate (GFPC) or phenolic with verified dielectric strength in excess of 2500V. Mersen is the only manufacturer to offer Class T blocks with copper connectors. Features: Unique integral DIN-rail adapters for 600V, 30 & 60A blocks; Full barrier design (30 & 60A) increases pole to pole safety; Unique adder-block design (30 & 60A) for design flexibility; Spring reinforcing standard for all 30 & 60A clips; Features high conductivity copper alloy fuse clips; Cool running high amperage (100 - 600A) connectors; Copper connectors available 30 - 600A - Certifications: All fuse blocks meet the requirements of UL 4248; UL listed, guide IZLT, File E52283; UL recognized component guide IZLT2, file E52283; CSA certified class 6225, File 32169
