Ferraz Shawmut - Mersen A60C175-121 93540-FUSE,FORM
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 782001935405
Amperage - 175 Amp
Applications - For the protection of Capacitors
Catalog Number - A60C175-121
Country of Origin - Mexico
Packaging
1 ea
EAN
30782001935406
Part #
194980
Catalog #
A60C175-121
Commercial reference
A60C175-121
12-Digit UPC:
782001935405
Amperage:
175 Amp
Applications:
For the protection of Capacitors
Catalog Number:
A60C175-121
Country of Origin:
Mexico
ERP_productname:
FRZ A60C175-121 93540-FUSE,FORM 480
Family Brand Name:
Ferraz Shawmut Canada, Inc.
Interrupt Rating:
200 kAIC
Length:
3.82 Inch
Mounting Type:
Direct Mount
Rated Voltage AC:
600 V
Tc Connection:
Screw-in
Type:
Low-Voltage Capacitor Fuses
Voltage:
600 Volt
SoneparProductId:
SKU_US_182937696
Mersen low-voltage capacitor fuses provide advanced safety for power correction and harmonic filtering equipment. A capacitor fuse isolates a shorted capacitor before it can damage surrounding equipment or personnel. Typical capacitor failures occur when the internal dielectric can no longer withstand the applied voltage, resulting in a low impedance current path and generating excessive heat and pressure that can cause violent case rupture. Mersen A60C fuses will isolate the shorted capacitor before case rupture occurs while routinely withstanding inrush current at startup. Features: High interrupting rating; Current-limiting; Capacitor inrush withstand capability; Direct mount; Optional blown fuse indication - Certifications: UL Recognized Component File E60314; Tested by UL to CSA standard C22.2 No. 248.1
