Ferraz Shawmut - Mersen A70P30-1 14.2 x 50.8 mm 30 Amp 700 Volt Semiconductor Protection Fuse
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 782001947125
Amperage - 30 Amp
Applications - For Protection of 700 V or Less DC Drives, UPS, Inverters, Reduced Voltage Starters
Catalog Number - A70P30-1
Country of Origin - Mexico
Packaging
1 ea
EAN
30782001947126
Part #
167005
Catalog #
A70P30-1
Commercial reference
A70P30-1
12-Digit UPC:
782001947125
Amperage:
30 Amp
Applications:
For Protection of 700 V or Less DC Drives, UPS, Inverters, Reduced Voltage Starters
Catalog Number:
A70P30-1
Country of Origin:
Mexico
ERP_productname:
FRZ A70P30-1 700V SEMICOND FUSE
Family Brand Name:
Ferraz Shawmut Canada, Inc.
Length:
2 Inch
Mounting Type:
Clip
Rated Voltage AC:
700 V
Tc Connection:
Ferrule
Type:
Round
Voltage:
700 Volt
SoneparProductId:
SKU_US_59210454
A70P Amp-Trap® Form 101 high speed fuses were developed for higher voltage AC and DC drives, UPS systems, reduced voltage motor starters and similar applications where lower l2t and superior reliability are needed. A70P is a very popular fuse, available in a wide range of ratings. Typically used for replacement. Features: Low I2t minimizes damage to protected components on short circuit; Controlled arc voltage reduces stress to circuit components during fuse clearing; Choice of mounting types helps in equipment design - Certifications: UL recognized component UL File E60314; AC: guide no. JFHR2 (10-1000A); DC: tested to UL standard 198L parameters (10-800A)
