Hubbell Wiring Device - Hubbell DR15ALDECO Receptacle, COMM GRD, 15A 125V, 5-15R, AL

Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783585127798
Amperage - 15 Amp
Applications - For Commercial Applications
Catalog Number - DR15AL
Color - Brown
Packaging
1 ea
EAN
00783585127798
Part #
193953
Catalog #
DR15AL
Commercial reference
DR15AL
12-Digit UPC:
783585127798
Amperage:
15 Amp
Applications:
For Commercial Applications
Catalog Number:
DR15AL
Color:
Brown
Conductor Size:
14-10 AWG
Country of Origin:
China
Current:
15 Amp
ERP_productname:
HUB DR15AL DECO RCPT, COMM GRD, 15A 125V, 5-15R, AL
Family Brand Name:
Hubbell Wiring Device-Kellems
Grade:
Commercial, Industrial
Heights:
3.28 Inch
Horsepower:
0.5 hp
Length:
1.29 Inch
Material:
Thermoplastic
Mounting Type:
Screw
NEMA:
5-15R
Number of Phases:
1 Phase
Number of Poles:
2 Pole
Number of Wires:
3 Wire
Size:
Standard Sized
Sub Brand:
Straight Blade
Tc Connection:
Back and Side Wired
Type:
Decorator
Voltage:
125 Volt
Wattage:
1875 Watt
Widths:
1.06 in
Wire Size:
14-10 AWG
SoneparProductId:
SKU_US_89251759
