Hubbell Wiring Device - Hubbell DR20ITR TAMP RES, DECO FACE, 20A 125V, IV

CopyCopy

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 783585144436

  • Amperage - 20 Amp

  • Applications - Commercial Specification Grade

  • Catalog Number - DR20ITR

  • Color - Ivory

Packaging

  • 1 ea

EAN

00783585144436

Part #

197576

Catalog #

DR20ITR

Commercial reference

DR20ITR

12-Digit UPC:

783585144436

Amperage:

20 Amp

Applications:

Commercial Specification Grade

Catalog Number:

DR20ITR

Color:

Ivory

Conductor Size:

14-12 AWG

Country of Origin:

China

Current:

20 Amp

ERP_productname:

HUB DR20ITR TAMP RES, DECO FACE, 20A 125V, IV

Family Brand Name:

Hubbell Wiring Device-Kellems

Grade:

Commercial Specification

Heights:

1.29 Inch

Horsepower:

1 hp

Length:

3.28 Inch

Material:

Nylon

Mounting Type:

Screw

NEMA:

5-20R

Number of Phases:

1 Phase

Number of Poles:

2 Pole

Number of Wires:

3 Wire

Size:

Standard Sized

Sub Brand:

Straight Blade

Tc Connection:

Back and Side Wired

Type:

Decorator, Tamper-Resistant

Voltage:

125 Volt

Wattage:

2500 Watt

Widths:

1.14 in

Wire Size:

12-10 AWG

SoneparProductId:

SKU_US_28989491

Straight Blade Devices, Receptacles, Tamper-Resistant Duplex, Decorator/Commercial/Industrial Grade, 2-Pole 3-Wire Grounding, 20A 125V, 5-20R, Ivory, Single Pack. Industry Standard(s): Certified to CSA, C22.2, No. 42; NEMA® WD-6 Compliant; UL Listed to UL498 File No. E2186 - Performance: Electrical - Current Interrupting - Certified for current interrupting at full rated current; Electrical - Dielectric Voltage - Withstands 2,000V minimum; Environmental - Flammability - UL 94 V-2; Environmental - Operating Temperatures - Maximum continuous 75±C minimum -40±C (w/o impact); Mechanical - Product Identification - Ratings are a permanent part of the device; Mechanical - Terminal Accommodation - #12-#10 AWG copper stranded or solid conductor only; Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA - Features: Tamper-resistant shutter complies with national electrical code requirements; Aesthetic Style Line® decorator design; Smooth face; Triple wipe contacts
