Hubbell Wiring Device - Hubbell DR20LATR TAMP RES, DECO FACE, 20A 125V, LA
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783585144450
Amperage - 20 Amp
Applications - For Commercial Indoor, Education, Healthcare, Hospitality, Manufacturing, Retail, Warehouse
Catalog Number - DR20LATR
Color - Light Almond
Packaging
1 ea
EAN
00783585144450
Part #
142846
Catalog #
DR20LATR
Commercial reference
DR20LATR
12-Digit UPC:
783585144450
Amperage:
20 Amp
Applications:
For Commercial Indoor, Education, Healthcare, Hospitality, Manufacturing, Retail, Warehouse
Catalog Number:
DR20LATR
Color:
Light Almond
Conductor Size:
14-12 AWG
Country of Origin:
China
Current:
20 Amp
ERP_productname:
HUB DR20LATR TAMP RES, DECO FACE, 20A 125V, LA
Family Brand Name:
Hubbell Wiring Device-Kellems
Grade:
Commercial Specification
Heights:
1.29 Inch
Horsepower:
1 hp
Length:
3.28 Inch
Material:
Nylon
Mounting Type:
Screw, Recessed/Flush
NEMA:
5-20R
Number of Phases:
1 Phase
Number of Poles:
2 Pole
Number of Wires:
3 Wire
Size:
Standard Sized
Sub Brand:
Straight Blade
Tc Connection:
Back and Side Wired
Type:
Decorator, Tamper-Resistant
Voltage:
125 Volt
Wattage:
2500 Watt
Widths:
1.14 in
Wire Size:
12-10 AWG
SoneparProductId:
SKU_US_32346864
