Hubbell Wiring Device - Hubbell HBL7940 Receptacle, SURF MT, 3P3W, 50A 125/250V, BK
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783585015392
Amperage - 50 Amp
Applications - Heavy duty, high leverage diagonal cutter
Catalog Number - HBL7940
Color - Black
Packaging
1 ea
EAN
00783585015392
Part #
164698
Catalog #
HBL7940
Commercial reference
HBL7940
12-Digit UPC:
783585015392
Amperage:
50 Amp
Applications:
Heavy duty, high leverage diagonal cutter
Catalog Number:
HBL7940
Color:
Black
Conductor Size:
10-4 AWG
Country of Origin:
USA
Current:
50 Amp
ERP_productname:
HUB HBL7940 RCPT, SURF MT, 3P3W, 50A 125/250V, BK
Family Brand Name:
Hubbell Wiring Device-Kellems
Heights:
2.06 Inch
Horsepower:
3 hp
Length:
5.06 Inch
Material:
Thermoplastic
Mounting Type:
Screw, Surface
NEMA:
10-50R
Number of Phases:
1 Phase
Number of Poles:
3 Pole
Number of Wires:
3 Wire Non-Grounding
Size:
Standard
Sub Brand:
Straight Blade
Tc Connection:
Back & Side Wired
Type:
Heavy Duty
Voltage:
125/250 Volt
Wattage:
12500 Watt
Widths:
2.5 in
Wire Size:
12-4 lb
SoneparProductId:
SKU_US_30625229
