Hubbell Wiring Device - Hubbell HBLDS10 100 Amp 3-Phase 3-Pole NEMA 4X Non-Metallic Unfused Disconnect Switch Enclosure
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783585430652
Actuator - Lever
Amperage - 100 Amp
Applications - Extra Heavy Duty Industrial Application
Catalog Number - HBLDS10
Packaging
1 ea
EAN
00783585430652
Part #
213709
Catalog #
HBLDS10
Commercial reference
HBLDS10
12-Digit UPC:
783585430652
Actuator:
Lever
Amperage:
100 Amp
Applications:
Extra Heavy Duty Industrial Application
Catalog Number:
HBLDS10
Color:
Gray
Country of Origin:
Poland
Current:
100 Amp
ERP_productname:
HUB HBLDS10 DISCONNECT SW
Enclosure:
Type 4X, IP69k
Family Brand Name:
Hubbell Wiring Device-Kellems
Heights:
5.94 Inch
Horsepower:
50 hp
Length:
11 Inch
Material:
Composite
Mounting Type:
Feet
Number of Phases:
3 Phase
Number of Poles:
3 Pole
Shape:
Square Top
Size:
11 in x 7.75 in x 5.94 in
Sub Brand:
Circuit-Lock®
Tc Connection:
Terminal Screws
Type:
Standard, 2 Position, Lever, Non-Fused, Snap
Voltage:
600 Volt
Wattage:
60000 Watt
Widths:
8.9 in
SoneparProductId:
SKU_US_25644479
