Ideal Industries - Ideal 89-206 Terminal Strip, 6-Circuit 30A/600V
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783250892068
Amperage - 30 Amp
Catalog Number - 89-206
Color - Black
Conductor Size - 22-10 AWG
Packaging
1 ea
EAN
00783250892068
Part #
200872
Catalog #
89-206
Commercial reference
89-206
12-Digit UPC:
783250892068
Amperage:
30 Amp
Catalog Number:
89-206
Color:
Black
Conductor Size:
22-10 AWG
ERP_productname:
IDE 89-206 6CKT TERMINAL STRIP
Family Brand Name:
Ideal Industries
Material:
Zinc
Mounting Type:
Surface
Number of Poles:
6 Pole
Torque Rating:
16 in-lb
Type:
Heavy Duty, 1-Piece
Voltage:
600 Volt
Wire Size:
22-10 AWG
SoneparProductId:
SKU_US_25452678
IDEAL Terminal Strips are designed and manufactured to be rugged, reliable, and easy to use. A thermoplastic base and corrosion-resistant screws and hardware provide extended service life. Optional accessories provide convenient, versatile application. Available in a wide variety of circuit configurations, electrical ratings and center spacings, an IDEAL terminal strip is available for virtually any job. Features: .562 (14.82mm) center spacing; Accepts wire sizes from 10 through 22 AWG Cu; #8-32 Philslot, zinc-plated steel terminal screws; Heavy-duty, corrosion-resistant screws, surface plates, and optional hardware; Rugged polyester thermoplastic base (UL Rated 94V-0); UL Recognized (E82048) and CSA Certified (LR15364)
