Ideal Industries - Ideal 89-406 Double Row Terminal Strip 6-Circuit 12-22AWG 20A/250V
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783250894062
Amperage - 20 Amp
Catalog Number - 89-406
Conductor Size - 22-12 AWG
ERP_productname - IDE 89-406 6P DBL ROW TERM STRIP
Packaging
1 ea
EAN
00783250894062
Part #
108676
Catalog #
89-406
Commercial reference
89-406
12-Digit UPC:
783250894062
Amperage:
20 Amp
Catalog Number:
89-406
Conductor Size:
22-12 AWG
ERP_productname:
IDE 89-406 6P DBL ROW TERM STRIP
Family Brand Name:
Ideal Industries
Material:
Zinc
Voltage:
250 Volt
Wire Size:
22-12 AWG
SoneparProductId:
SKU_US_25517436
IDEAL Terminal Strips are designed and manufactured to be rugged, reliable, and easy to use. A thermoplastic base and corrosion-resistant screws and hardware provide extended service life. Optional accessories provide convenient, versatile application. Available in a wide variety of circuit configurations, electrical ratings and center spacings, an IDEAL terminal strip is available for virtually any job. Features: .437 (11.10mm) center spacing; Accepts wire sizes from 12 through 22 AWG Cu; #6-32 Philslot, zinc-plated steel terminal screws; Heavy-duty, corrosion-resistant screws, surface plates, and optional hardware; Rugged polyester thermoplastic base (UL Rated 94V-0); UL Recognized (E82048) and CSA Certified (LR15364)
