Ideal Industries - Ideal 89-504 Terminal Strip 4-Circuit 6-22AWG 60A/600V
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783250895045
Amperage - 60 Amp
Catalog Number - 89-504
Conductor Size - 22-6 AWG
ERP_productname - IDE 89-504 4P DBL ROW TERM STRIP
Packaging
1 ea
EAN
00783250895045
Part #
150590
Catalog #
89-504
Commercial reference
89-504
12-Digit UPC:
783250895045
Amperage:
60 Amp
Catalog Number:
89-504
Conductor Size:
22-6 AWG
ERP_productname:
IDE 89-504 4P DBL ROW TERM STRIP
Family Brand Name:
Ideal Industries
Material:
Brass
Voltage:
600 Volt
Wire Size:
22-6 AWG
SoneparProductId:
SKU_US_25555144
IDEAL, Terminal Strip, Wire Size: 22 - 6 AWG, Spacing: 0.625 IN, Amperage Rating: 60 AMP, Voltage Rating: 600 V, Material: Nickle-Plated Brass, Number Of Circuits: 4, Torque Rating: 20 IN-LB, Terminal Screw Size: 4 Features: Available in standard or shorting block styles; .625 in. (15.88mm) center spacing; Accepts wire sizes from 6 through 22 AWG Cu; #10-32 Philslot, nickel-plated brass terminal screws; Heavy-duty, corrosion-resistant screws, surface plates and optional hardware; Rugged polyester thermoplastic base (UL Rated 94V-0); Operating temperature rated from 130± C (260± F) to -40± C (-40± F); UL Recognized (E82048) and CSA Certified (LR15364)
