Ideal Industries - Ideal 89-509 Double Row Terminal Shorting Block 8-Circuit 6-22AWG 60A/600V
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783250895090
Amperage - 60 Amp
Catalog Number - 89-509
Conductor Size - 22-6 AWG
ERP_productname - IDE 89-509 TERMINAL STRIP,IDEAL,CSA,UL LISTED,WIRE SZ: 22 - 6 AWG,SPACING: 0.625 IN,60 AMP
Packaging
1 ea
EAN
00783250895090
Part #
110744
Catalog #
89-509
Commercial reference
89-509
12-Digit UPC:
783250895090
Amperage:
60 Amp
Catalog Number:
89-509
Conductor Size:
22-6 AWG
ERP_productname:
IDE 89-509 TERMINAL STRIP,IDEAL,CSA,UL LISTED,WIRE SZ: 22 - 6 AWG,SPACING: 0.625 IN,60 AMP
Family Brand Name:
Ideal Industries
Material:
Brass
Voltage:
600 Volt
Wire Size:
22-6 AWG
SoneparProductId:
SKU_US_25309440
IDEAL Terminal Strips are designed and manufactured to be rugged, reliable, and easy to use. A thermoplastic base and corrosion-resistant screws and hardware provide extended service life. Optional accessories provide convenient, versatile application. Available in a wide variety of circuit configurations, electrical ratings and center spacings, an IDEAL terminal strip is available for virtually any job. Features: .625 (15.88mm) center spacing; Accepts wire sizes from 6 through 22 AWG Cu; #10-32 Philslot, nickel-plated brass terminal screws; Heavy-duty, corrosion-resistant screws, surface plates, and optional hardware; Rugged polyester thermoplastic base (UL Rated 94V-0); UL Recognized (E82048) and CSA Certified (LR15364)
