Ilsco - ILSCO CSWN-500-38 CU CMP NARROW, 50
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783669685749
Applications - Copper Compression Lug
Catalog Number - CSWN-500-38
Color - Silver
Conductor Material - Copper
Packaging
1 ea
EAN
00783669685749
Part #
453370
Catalog #
CSWN-500-38
Commercial reference
CSWN-500-38
12-Digit UPC:
783669685749
Applications:
Copper Compression Lug
Catalog Number:
CSWN-500-38
Color:
Silver
Conductor Material:
Copper
ERP_productname:
ILS CSWN-500-38 CU CMP NARROW, 500 KCMIL, BOLT 3/8, T UL
Family Brand Name:
Ilsco
Heights:
1.17 Inch
Length:
2.97 Inch
Material:
Copper
Number of Holes:
1 Hole
Size:
L:2.907;W:1.062;H:1.107 IN
Sub Brand:
Surecrimp
Type:
CSWN:SHORT NARROW W/SIGHT
Voltage:
35 Volt
Widths:
1.062 in
SoneparProductId:
SKU_US_29389097
Surecrimp Copper Compression Lug, Copper material, Tin plated connector,Standard barrel, narrow tang, 1 mounting hole(s), mounting bolt/stud size 3/8 in, UL 486A/B Listed, UL 467 Listed, C22.2 No. 65-03, 180. connecting angle, Copper Primary Conductor 500 kcmil, Contains DE-OX®, sight window, Square tang end, flex conductor range 350 G,H,I,K,M 373.7 DLO, rated for 35 kV, die color code Brown, primary color Silver, die index I-87,
