Intermatic, Inc - INT-MAT EK4035S NIGHTFOX Button Ele
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 078275152397
Applications - Outdoor Lighting Control
Catalog Number - EK4035S
Color - Gray
Country of Origin - Mexico
Packaging
1 ea
EAN
00078275152397
Part #
174045
Catalog #
EK4035S
Commercial reference
EK4035S
12-Digit UPC:
078275152397
Applications:
Outdoor Lighting Control
Catalog Number:
EK4035S
Color:
Gray
Country of Origin:
Mexico
Depths:
1-1/4 Inch
ERP_productname:
INTM EK4035S BUTTON ELECTRONIC PHOTOCONTROL, 480 V
Enclosure:
Polycarbonate
Family Brand Name:
NA
Heights:
2-1/4 Inch
Size:
1.31 WIDTH x 1.25 DEPTH x 2.25 HIGH IN; 3.35 WIDTH x 3.18 DEPTH x 5.72 HEIGHT CM
Tc Connection:
Color Coded Lead
Type:
Button Style Electronic Photocell
Widths:
1.313 in
SoneparProductId:
SKU_US_219242347
NIGHTFOX electronic photocontrols permanently install on outdoor electrical boxes, in-wall boxes or outdoor lighting fixtures. Ideal for LED fixtures with long-life expectations. Mounts internally to an enclosure with a minimum installation hole size of 5/8. diameter. Comes with 9" wire leads. Features: Non-drift silicon light sensor with IR filter; DC relay with zero-crossing circuitry for extended life; Conformal coated PCB; 15-year design life; Exceeds 10,000 ON/OFF switching cycles; Fail ON mode; Ideal for single or multifixture HID and LED installations; 220 J MOV surge protection element; Mounts internally to enclosure; Features 3/8\" - 18 NPSM thread for a minimum installation hole size of 5/8 inch diameter
