Intermatic, Inc - INT-MAT EK4235S NightFox™ Stem and

CopyCopy

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 078275152410

  • Applications - Outdoor Lighting Control

  • Catalog Number - EK4235S

  • Country of Origin - Mexico

  • Depths - 1-1/4 Inch

Packaging

  • 1 ea

EAN

00078275152410

Part #

125212

Catalog #

EK4235S

Commercial reference

EK4235S

12-Digit UPC:

078275152410

Applications:

Outdoor Lighting Control

Catalog Number:

EK4235S

Country of Origin:

Mexico

Depths:

1-1/4 Inch

ERP_productname:

INTM EK4235S STEM SWIVEL MOUNT ELECTRONIC PHOTOCONTROL, 480 V

Enclosure:

Polycarbonate

Family Brand Name:

NA

Heights:

5-5/8 Inch

Size:

1.31 WIDTH x 1.25 DEPTH x 2.25 HIGH IN; 3.35 WIDTH x 3.18 DEPTH x 5.72 HEIGHT CM

Tc Connection:

Color Coded Lead

Type:

Stem and Swivel Mount Electronic Photocell

Widths:

1.313 in

SoneparProductId:

SKU_US_209605139

NIGHTFOX electronic photocontrols permanently install on outdoor electrical boxes or outdoor lighting fixtures. Ideal for LED fixtures with long-life expectations. ..-14 NPSM threaded stem fits standard outlet boxes and wall packs with a minimum installation hole size of 7/8. diameter. Come with 9" wire leads. Features: Non-drift silicon light sensor with IR filter; DC relay with zero-crossing circuitry for extended life; Conformal coated PCB; 15-year design life; Exceeds 10,000 ON/OFF switching cycles; Fail ON mode; Ideal for single or multifixture HID and LED installations; 220 J MOV surge protection element; 1?2\"-14 NPSM threaded stem fits standard outlet boxes and wall packs for a minimum installation hole size of 7/8 inch diameter; #18 AWG wire leads
