Intermatic, Inc - INTM ET8215CPD82 7D 30A 2XSPSTORDPST120-277V NEMA3R PLST

CopyCopy

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 078275109834

  • Amperage - 30 Amp

  • Applications - interior lighting, exterior lighting, electric pumps, electric motor control

  • Catalog Number - ET8215CPD82

  • Color - Gray

Packaging

  • 1 ea

EAN

00078275109834

Part #

122598

Catalog #

ET8215CPD82

Commercial reference

ET8215CPD82

12-Digit UPC:

078275109834

Amperage:

30 Amp

Applications:

interior lighting, exterior lighting, electric pumps, electric motor control

Catalog Number:

ET8215CPD82

Color:

Gray

Depths:

101.6 mm

ERP_productname:

INTM ET8215CPD82 7D 30A 2XSPSTORDPST120-277V NEMA3R PLST

Enclosure:

NEMA 3R Plastic

Enclosure Type:

Outdoor Type 3R Plastic

Family Brand Name:

Intermatic

Heights:

254 mm

Horsepower:

1 hp

Input Voltage:

208-277 V

Mounting Type:

Wall Mount

Number of Circuits:

2

Number of Poles:

1 Pole

Product Category:

Medical/Dental/Veterinary - Timers

Product Type:

Medical/Dental/Veterinary - Timers

Tc Connection:

Teeter Type

Type:

Medical/Dental/Veterinary - Timers

Voltage:

277 Volt

Widths:

165.1 mm

SoneparProductId:

SKU_US_31037741

This series offers an easy way to upgrade from a basic mechanical time switch to an electronic time switch. These timers will allow for up-to-the-minute programming, battery backup for power loss, 14 ON/OFF events per circuit, and automatic daylight saving time corrections without the need of user interaction. They come in standard 24-hour, 7-day, and 7-day astronomic (sunrise to sunset) versions. Applications: Interior Lighting; Exterior Lighting; Electric Pumps; Electric Motor Control; Various Other Electrical Loads - Features: Selector switch to determine input voltage between 120-277 VAC, 50/60 Hz; 14 ON/OFF events per circuit; To-the-minute accuracy; Temporary override or permanent manual override; Automatic Daylight Saving Time adjustment; Astronomic models enable dusk-to-dawn scheduling - Related Accessories and Parts: ET8215CM
