Klein Tool - Klein VDV826-729 Pass-Thru Modular Data Plugs RJ45-CAT6, 10-Pack

CopyCopy

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 092644690921

  • Applications - For Voice and Data

  • Catalog Number - VDV826-729

  • Color - Clear

  • Country of Origin - Taiwan

Packaging

  • 1 ea

EAN

00092644690921

Part #

182610

Catalog #

VDV826-729

Commercial reference

VDV826-729

12-Digit UPC:

092644690921

Applications:

For Voice and Data

Catalog Number:

VDV826-729

Color:

Clear

Country of Origin:

Taiwan

Depths:

0.885 Inch

ERP_productname:

KLEI VDV826-729 PASS-THRU DATA PLUG. CAT6, 10 PK

Family Brand Name:

Klein Tools, Inc.

Heights:

0.453 Inch

Length:

7/8 Inch

Material:

Gold

Number of Positions:

8

Overall Length:

0.875 in

Sub Brand:

Pass-Thru™

Type:

RJ45

Widths:

0.094 in

SoneparProductId:

SKU_US_26152210

Exclusive Klein-designed Pass-Thru™modular plugs for fast, reliable connector installations for data applications. Cable easily passes through connector for consistent and secure termination. Saves time, trims flush to end face when used with Klein Tools Pass-Thru™ Modular Crimper VDV226-110, and eliminates wasted materials. These CAT6 connectors are fully compliant with all PoE standards. Use with Klein Tools Pass-Thru™ Modular Crimper, VDV226-110. Features: Klein exclusive Pass-Thru™ Connectors provide fast, reliable connector installations for data applications; CAT6 Cable easily passes through connector to visually ensure that wires are in the correct order for consistent and secure terminations; 50. inch gold plating on all contact surfaces; Meets or Exceeds all PoE and PoE+ requirements for performance; Category 6 performance per EIA/TIA B.2. FCC compliant, UL rated, RoHS compliant; For use with Klein Tools Pass-Thru™ Modular Crimper VDV226-110; 10-Pack; 8 position, 8 contact Pass Through style data plug for solid or stranded cable; Max diameter for CAT6 Pass-Thru™ Connectors is 0.04\" (1.01 mm); Pass-Thru Technology; Meets All PoE Standards; Fully compliant with Power Over Ethernet (PoE and PoE+) standards; 50 .-inch minimum gold plating on all contact surfaces; Category 6 performance per EIA/TIA B.2.and RoHS compliant - Warnings: Do NOT use on energized circuits or cabling systems
