Lithonia Lighting - LITH TFX3 LED 40K MVOLT IS DDBXD Fl

CopyCopy

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 193047670265

  • Buy American - Y

  • Catalog Number - TFX3LED40KMVOLTISDDBXD

  • Color - Bronze

  • Color Temperature - 4000 K

Packaging

  • 1 ea

EAN

00193047670265

Part #

208809

Catalog #

TFX3LED40KMVOLTISDDBXD

Commercial reference

TFX3LED40KMVOLTISDDBXD

12-Digit UPC:

193047670265

Buy American:

Y

Catalog Number:

TFX3LED40KMVOLTISDDBXD

Color:

Bronze

Color Temperature:

4000 K

Country of Origin:

China

ERP_productname:

LITH TFX3LED40KMVOLTISDDBXD LED FIXTURE

Environment:

Outdoor

Family Brand Name:

Lithonia Lighting

Finish:

Gloss

Fixture Type:

Floodlight

Heights:

20-3/4 Inch

Length:

5 Inch

Lumens:

25,600 Lumen

Material:

Aluminum

Mounting Type:

Pole Mount,Tenon Slipfitter

Shape:

Rectangle

Size:

18x18x20.75

Type:

Floodlight

Voltage:

120-277 Volts

Widths:

18

SoneparProductId:

SKU_US_133292696

The TFX3 delivers 25,600 lumens and can replace up to 400W metal halide. The TFX LED floodlight family is an industry-leading distributor stock solution providing cost-effective and energy-efficient solutions to replace HID floodlights. In addition, payback can be achieved in less than two years, due to DLC Premium listing and 140 lumens per watt efficacy. For the full solution, the TFX comes in four sizes delivering 7,000 to 41,000 lumens replacing 70W to 400W metal halide luminaires. Features: The TFX LED flood luminaire is a cost-effective, energy-efficient and long-life solution for replacing metal halide or HPS floodlights; Replace up to 400W metal halide while saving over 60% in energy costs; Hardwired on/off capability only; UL Certified to meet US and Canadian standards, suitable for wet locations, IP66 rated, DesignLights Consortium (DLC) Premium qualified product; 120V-277V and the integral slipfitter option mates with standard 2-3/8 inch tenons for pole-top mounting and is suitable for aiming in any orientation while being tilted from 0± horizontal facing downwards up to 180± horizontal facing upwards; Light engine(s) configurations consist of high-efficacy LEDs and LED lumen maintenance is L90/100,00 hours; Die-cast aluminum main body with optimal thermal management that both enhances LED efficacy and extends component life where the light engines and housing are IP66 rated and sealed against moisture or environmental contaminants; No emergency battery back-up available in this version; Five-year limited warranty; 18 in x 20-3/4 in x 5 in; Delivering 25,600 lumens the TFX3 can replace up to 400W metal halide while saving over 60% in energy costs; Cost effective and energy efficient with payback within one year; Adjustable slipfitter is easy to mount on any 2-3/8 inch OD tenon
