NSi - NSI CTH-111 1 to 1/4 AWG Wire Size Main Blue 25-Pack Copper Compression Connector C-Tap
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 662381098108
Applications - Terminate, Splice, Tap Power Connectors
Catalog Number - CTH-111
Color - Blue
Conductor Size - 4/0 AWG
Packaging
1 ea
EAN
00662381098108
Part #
237716
Catalog #
CTH-111
Commercial reference
CTH-111
12-Digit UPC:
662381098108
Applications:
Terminate, Splice, Tap Power Connectors
Catalog Number:
CTH-111
Color:
Blue
Conductor Size:
4/0 AWG
Country of Origin:
USA
ERP_productname:
NSI CTH-111 4/0-1 MAIN COPPER C TAP
Family Brand Name:
NSI Industries
Finish:
Copper
Length:
33 mm
Material:
Copper
Size:
4/0-8 AWG
Sub Brand:
Copper Compression
Type:
C-Taps
Voltage:
600 Volt
Widths:
20 mm
SoneparProductId:
SKU_US_25397560
Heavy Duty Copper C Tap Grounding Connector for 4/0 to 1 AWG APPLICATIONS: Copper "C" Taps ensure positive, all around compression with low-resistance and high pull-out values. Made of high conductivity copper, they satisfy the requirements of NEC250-81 and 250-91 for connecting to the grounding electrode system. Rated 600 Volts. Features: These taps ensure positive, all-around compression with low resistance and high pull-out values; Made of high conductivity copper, they satisfy the requirements of NEC250 for connecting to the grounding electrode system; Rated for 600V applications; Rated for CLASS B OR C BUILDING WIRE CU CABLE ONLY. - Certifications and Standards: cULus; UL Listed; UL 486A, UL 467 - Additional Notes: FOR TOOL/DIE CRIMPING INFORMATION, PLEASE SEE TABLE ON PAGE 88 - Related Products:
