NSi - NSI PT250 250 MCM Brown Tinned Aluminum 1-Conductor Stranded Bi-Metallic Pin Terminal

Essential specifications

12-Digit UPC - 662381033086
Applications - Terminate, Splice, Tap Power Connectors
Catalog Number - PT250
Color - Brown
Conductor Size - 250 kcmil

Packaging

1 ea

EAN

00662381033086

Part #

345315

Catalog #

PT250

Commercial reference

PT250

12-Digit UPC:

662381033086

Applications:

Terminate, Splice, Tap Power Connectors

Catalog Number:

PT250

Color:

Brown

Conductor Size:

250 kcmil

Country of Origin:

India

ERP_productname:

NSI PT250 #250 PIN TERMINAL

Family Brand Name:

NSI Industries

Finish:

Tin Plated

Heights:

1.14 Inch

Length:

3.86 Inch

Material:

Aluminum

Number of Conductors:

Number of Poles:

1 Pole

Size:

L=3.85 - OD=1.16 - ID=.653 - Pin Dia=.440

Sub Brand:

Pin Terminals

Tc Connection:

3/0 Pin

Type:

Bi-Metallic Pin

Voltage:

600 Volt

Widths:

1.14 in

Wire Size:

250 kcmil

SoneparProductId:

SKU_US_57851492

Stranded Bi-Metallic Pin Terminal 250 MCM Stranded Bi-Metallic Pin Terminals is designed to facilitate termination of aluminum conductors. Tin-plated stranded copper pin. Connector bores are coated with oxide inhibitor. Supplied with EPDM insulating cover. UL 486B listed. Rated 600 volts. Certifications and Standards: UL Listed; UL 486A-486B - Features: Designed to facilitate termination of aluminum conductors; Pin - Stranded copper, tin plated; Supplied with EPDM insulating cover; Connector bores are coated with oxide inhibitor; Wire connector rated for 35kV max - Related Products:
