Panduit Corp - PAN DNF18250FIMX-2K Reel Smart™ DNF
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 074983343430
Buy American - Y
Catalog Number - DNF18250FIMX-2K
Color - Red
Conductor Size - 22 AWG
Packaging
1 ea
EAN
00074983343430
Part #
108799
Catalog #
DNF18250FIMX-2K
Commercial reference
DNF18250FIMX-2K
12-Digit UPC:
074983343430
Buy American:
Y
Catalog Number:
DNF18250FIMX-2K
Color:
Red
Conductor Size:
22 AWG
Country of Origin:
Mexico
ERP_productname:
PAND DNF18250FIMX-2K MALE DISCONNECT, NYLON FULLY INSULATED,
Family Brand Name:
Panduit Corp.
Finish:
Nickel
Heights:
0.29 Inch
Material:
Brass
Overall Length:
0.97 in
Sub Brand:
Reel Smart™
Tc Connection:
Expanded
Type:
Disconnect
Voltage:
600 Volt
Widths:
0.41 in
Wire Size:
18 AWG
SoneparProductId:
SKU_US_181735357
The vibration resistant male tab disconnect is made of brass and is nickel-plated. It is fully insulated in a red, nylon standard housing and has an expanded wire entry area. It has a tab size of 0.250 x 0.032" (6.3 x 0.8 mm) and supports a wire range of 22-18 AWG (0.5-1.0 mm.). It is 0.97" (24.6 mm) long and 0.41" (10.4 mm) wide. The disconnect has an expanded barrel configuration and a butted seam barrel. It comes in reels of 2000 pieces. Standards and Certifications: Standards Met: UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153
