Panduit Corp - Panduit DNF10-250FIMB-Q Nylon Fully Insulated Male Disconnect
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 074983119028
Buy American - Y
Catalog Number - DNF10-250FIMB-Q
Color - Yellow
Conductor Size - 12-10 AWG
Packaging
1 ea
EAN
00074983119028
Part #
100146
Catalog #
DNF10-250FIMB-Q
Commercial reference
DNF10-250FIMB-Q
12-Digit UPC:
074983119028
Buy American:
Y
Catalog Number:
DNF10-250FIMB-Q
Color:
Yellow
Conductor Size:
12-10 AWG
Country of Origin:
Mexico
ERP_productname:
PAND DNF10-250FIMB-Q MALE DISCONNECT NYLON FULLY INSULATED
Family Brand Name:
Panduit Corp.
Finish:
Nickel
Heights:
0.36 Inch
Material:
Copper
Overall Length:
0.96 in
Sub Brand:
Pan-Term®
Tc Connection:
Standard
Type:
Loose-Piece
Voltage:
600 Volt
Widths:
0.45 in
Wire Size:
10 AWG
SoneparProductId:
SKU_US_25770486
The vibration resistant male tab disconnect is made of copper and is nickel-plated. It is fully insulated in a yellow, oversized nylon housing. It has a tab size of 0.250 x 0.032" (6.3 x 0.8 mm) and supports a wire range of 12-10 AWG (4.0-6.0 mm.). It is 0.96" (24.4 mm) long and 0.22" (5.6 mm) wide. The disconnect has a standard barrel configuration and a butted seam barrel. It comes in bottles of 25. Standards and Certifications: Standards Met: UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153 - Prop 65: No
