Panduit Corp - Panduit SCS2-Q Standard Barrel Copper Compression Butt Splice
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 074983903153
Buy American - Y
Catalog Number - SCS2-Q
Color - Brown
Conductor Size - 2 AWG
Packaging
1 ea
EAN
00074983903153
Part #
103852
Catalog #
SCS2-Q
Commercial reference
SCS2-Q
12-Digit UPC:
074983903153
Buy American:
Y
Catalog Number:
SCS2-Q
Color:
Brown
Conductor Size:
2 AWG
Country of Origin:
Mexico
ERP_productname:
PAND SCS2-Q 2AWG CABLE SPLICE
Family Brand Name:
Panduit Corp.
Finish:
Tin Plated
Material:
Copper
Overall Length:
1.87 in
Size:
NA
Sub Brand:
Pan-Lug™
Type:
Compression Splice
Voltage:
35 kV
SoneparProductId:
SKU_US_25541542
The SCS2-Q Copper Compression Lug Lug, standard barrel, has color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection. An inspection window aids to visually assure full conductor insertion, and the tin-plate material helps to inhibit corrosion. UL Listed and CSA Certified to 35 KV and temperature rated to 90.C. Standards and Certifications: Standards Met: UL Listed and CSA Certified to 35 kV and temperature rated to 90±C - Prop 65: No
