Pass & Seymour / Legrand - P&S PSDS30 30A 600V SS NON-FUS SAFE

CopyCopy

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 785007133547

  • Amperage - 30 Amp

  • Buy American - Y

  • Catalog Number - PSDS30

  • Country of Origin - USA

Packaging

  • 1 ea

EAN

00785007133547

Part #

251030

Catalog #

PSDS30

Commercial reference

PSDS30

12-Digit UPC:

785007133547

Amperage:

30 Amp

Buy American:

Y

Catalog Number:

PSDS30

Country of Origin:

USA

Depths:

6.52 Inch

ERP_productname:

PASS PSDS30 30A 600V SS NON-FUS SAFESW

Family Brand Name:

Legrand

Heights:

8.4 Inch

NEMA Size:

12,4X

Sub Brand:

Pass & Seymour

Type:

Stainless Steel Safety Switches

Voltage:

600 Volt

Widths:

4.9 in

SoneparProductId:

SKU_US_52965902

30 Amps Stainless Steel Safety Switch.Legrands 316-Grade Stainless Steel Safety Switches are designed to provide superior corrosion resistance in harsh environments like food and beverage processing plants where wash down/hose down at extreme temperatures is a daily necessity, as well as environments where salts, acids, and chemicals are prevalent. Legrands Stainless Steel Safety Switches with NEMA 4X/12, IP66, 67, and 69K ratings are the best solution for durability and personnel safety in any environment. Features: Type 316 grade stainless steel provides superior resistance to corrosion.; 8 conduit entry points for flexible installation options.; Certified by the National Sanitation Foundation (NSF) for hygiene requirements in food & beverage processing.; Can accommodate up to 3 sets of auxiliary contacts for control circuit applications.; 3/4'' standoffs on mounting feet allow adequate space for runoff and inspection behind the switch.; Water- and dust-tight enclosure rated NEMA 3R, 4, 4X,12K and IP66,67,69 for protection against high-pressure, high-temperature water from multiple directions.; High-visibility yellow and red handle can be padlocked to meet OSHA lockout/tagout requirements.; OSHA-compliant Lockout/Tagout.; Multiple drill points for ease of installation (each side and back).; No labels on cover, stamped-in ON/OFF.; Inability to remove cover when in ON position.; Captive cover screws.; Compact footprint. - Certifications: cULus Listed
