Pass & Seymour / Legrand - P&S TR5262GRY RECEP DUP TR B+S WIRE

CopyCopy

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 785007243789

  • Amperage - 15 Amp

  • Applications - For Commercial Applications

  • Catalog Number - TR5262GRY

  • Color - Gray

Packaging

  • 1 ea

EAN

00785007243789

Part #

149786

Catalog #

TR5262-GRY

Commercial reference

TR5262-GRY

12-Digit UPC:

785007243789

Amperage:

15 Amp

Applications:

For Commercial Applications

Catalog Number:

TR5262GRY

Color:

Gray

Conductor Size:

14-10 AWG

Country of Origin:

Mexico

Depths:

1.13 Inch

ERP_productname:

PASS TR5262-GRY RECEP DUP TR B+S WIRE 15A/125V GRY

Family Brand Name:

Pass & Seymour

Grade:

Specification

Heights:

2.635 Inch

Material:

Thermoplastic

Mounting Type:

Wall

NEMA:

5-15R

Number of Phases:

3 Phase

Number of Poles:

2 Pole

Number of Wires:

3 Wire

Size:

5.13x2x1.4

Sub Brand:

Pass & Seymour

Type:

Receptacles

Voltage:

125 Volt

Widths:

1.322 in

Wire Size:

10 AWG

SoneparProductId:

SKU_US_52810061

Tamper-Resistant Hard Use Spec Grade Receptacle, Back and Side Wire, 15A, 125V Features: Dual mechanical shutter system to help prevent insertion of foreign objects.; AC receptacles available in 15 and 20A, 125V.; Easily accessed break-off line-contact connecting tab for fast and easy split-circuit wiring.; Backed-out tri-drive brass terminal screws for faster installation.; Internal screw-pressure-plate back and side wire capability.; Two back wire holes for additional wiring flexibility.; .032 inch thick brass triple-wipe power contacts.; Two drive screws anchor steel strap to back body and face where abrupt removal torque is greatest.; For covering patents, see www.legrand.us/patents.; Temperature Rise: Maximum 30±C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60±C, minimum -40±C without impact - Certifications: cULus Listed
