Pass & Seymour / Legrand - Pass & Seymour 2085-BK 20 Amp 125 VAC 2-Wire NEMA 5-20R Black Thermoplastic Decorator Dead Front GFCI Receptacle

CopyCopy
Pass & Seymour / Legrand - Pass & Seymour 2085-BK 20 Amp 125 VAC 2-Wire NEMA 5-20R Black Thermoplastic Decorator Dead Front GFCI Receptacle

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 785007423396

  • Amperage - 20 Amp

  • Catalog Number - 2085BK

  • Color - Black

  • Depths - 0.98 Inch

Packaging

  • 1 ea

EAN

00785007423396

Part #

226137

Catalog #

2085-BK

Commercial reference

2085-BK

12-Digit UPC:

785007423396

Amperage:

20 Amp

Catalog Number:

2085BK

Color:

Black

Depths:

0.98 Inch

ERP_productname:

PASS 2085-BK GFCI DEAD FRONT 20A 125V 20A FD BK

Family Brand Name:

Pass & Seymour

Grade:

Specification

Heights:

4.2 Inch

Length:

4.2 Inch

NEMA:

5-20R

Type:

Dead Front

Voltage:

125 Volt

Widths:

1.72 in

SoneparProductId:

SKU_US_27101820

From the innovator of the product category, comes a full range of Pass & Seymour GFCI receptacles to enhance safety, shorten installation times and increase productivity on the jobsite. With high-impact-resistant, thermoplastic construction, our spec-grade GFCI are the most durable GFCI available. Also features patented SafeLock™ Protection.if critical components are damaged and ground fault protection is lost, power to the receptacle is disconnected. Available Options: Spec Grade Dead Front 20A GFCI, Light Almond; Spec Grade Dead Front 20A GFCI, Ivory; Spec Grade Dead Front 20A GFCI, Black; Spec Grade Dead Front 20A GFCI, White - Features & Benefits: 1/4\" thinner than competitors' GFCIs; leaves more room for wires in the box.; Side or internal screw-pressure-plate back wire with #10 . #14 AWG solid or stranded copper wire. Two back wire holes per terminal. GFCIs with Auto-Ground assure a positive ground to metal box.; Extra-long strap. Button colors match the device face. Dual-direction test and reset buttons. Class A rated GFCI. Supplied with matching TP26 nylon wall plate. Tri-drive screws.; 10kA short circuit rating.; Mounting screws are shipped captive in the device and wall plate for easier installation.; For covering patents, see www.legrand.us/patents.; Exceeds UL943 voltage surge requirements; survives 100x the required UL 3kA/6kV voltage surge test cycles. FSUL Listed (Federal Specification WC596). Trip indicator light (red LED).; Ground screw has a back wire clamp for easy installation.
