Pass & Seymour / Legrand - Pass & Seymour 26242-BK Heavy-Duty Decorator Spec Grade Duplex Receptacle Side Wire 15A 125V - Black
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 785007784350
Catalog Number - 26242BK
Color - Black
Country of Origin - Mexico
Depths - 0.833 Inch
Packaging
1 ea
EAN
00785007784350
Part #
214318
Catalog #
26242-BK
Commercial reference
26242-BK
12-Digit UPC:
785007784350
Catalog Number:
26242BK
Color:
Black
Country of Origin:
Mexico
Depths:
0.833 Inch
ERP_productname:
PASS 26242-BK RECP DUP SPLEX 15A 125V S-WIRE BK
Family Brand Name:
Legrand
Finish:
Gloss
Heights:
2.635 Inch
Material:
Thermoplastic
Mounting Type:
Flush, Screw
Sub Brand:
Pass & Seymour
Type:
Heavy Duty
Widths:
1.322 in
SoneparProductId:
SKU_US_57950613
Heavy-Duty Decorator Spec Grade Duplex Receptacle Side Wire 15amp 125volt Brown Features: Corrosion-resistant, plated steel strap locked into assembly to prohibit strap from bending away from body.; One-piece, brass, triple-wipe power contacts for lasting retention.; Heavy-duty compact design for easier installation and long lasting performance.; Easily accessed break-off, line-contact connecting tab for fast, easy split-circuit wiring.; Impact-resistant nylon face.; Terminal compartments isolated from each other for positive conductor containment.; Tri-drive terminal and mounting screws.; Auto-ground clip assures positive ground.; For covering patents, see www.legrand.us/patents.; Temperature Rise: Maximum 30±C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60±C, minimum -40±C without impact - Certifications: cULus Listed; Federal Spec Listed
