Pass & Seymour / Legrand - Pass & Seymour 26242-W Heavy-Duty Decorator Spec Grade Duplex Receptacle Side Wire 15A 125V - White

CopyCopy
Pass & Seymour / Legrand - Pass & Seymour 26242-W Heavy-Duty Decorator Spec Grade Duplex Receptacle Side Wire 15A 125V - White

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 785007784411

  • Amperage - 15 Amp

  • Applications - Commercial Grade

  • Catalog Number - 26242W

  • Color - White

Packaging

  • 1 ea

EAN

00785007784411

Part #

163478

Catalog #

26242-W

Commercial reference

26242-W

12-Digit UPC:

785007784411

Amperage:

15 Amp

Applications:

Commercial Grade

Catalog Number:

26242W

Color:

White

Conductor Size:

14-10 AWG

Country of Origin:

Mexico

Depths:

0.833 Inch

ERP_productname:

PASS 26242-W RECP DUP SPLEX 15A 125V S-WIRE WH

Family Brand Name:

Pass & Seymour

Finish:

Decor, Gloss

Grade:

Specification

Heights:

2.635 Inch

Material:

Nylon

Mounting Type:

Wall, Flush

NEMA:

5-15R

Number of Poles:

2 Pole

Number of Wires:

3 Wire

Size:

1.322 L x .833 W x 3.813 H In

Sub Brand:

Pass & Seymour

Tc Connection:

Side wire

Type:

Decorator, Heavy Duty

Voltage:

125 Volt

Widths:

1.322 in

Wire Size:

10 AWG

SoneparProductId:

SKU_US_26353895

Heavy-Duty Decorator Spec Grade Duplex Receptacle Side Wire 15amp 125volt Brown Features: Corrosion-resistant, plated steel strap locked into assembly to prohibit strap from bending away from body.; One-piece, brass, triple-wipe power contacts for lasting retention.; Heavy-duty compact design for easier installation and long lasting performance.; Easily accessed break-off, line-contact connecting tab for fast, easy split-circuit wiring.; Impact-resistant nylon face.; Terminal compartments isolated from each other for positive conductor containment.; Tri-drive terminal and mounting screws.; Auto-ground clip assures positive ground.; For covering patents, see www.legrand.us/patents.; Temperature Rise: Maximum 30±C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60±C, minimum -40±C without impact - Certifications: cULus Listed
