Pass & Seymour / Legrand - Pass & Seymour 26252-CD 15A 125V Dual Control Decorator Receptacle Brown

CopyCopy

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 785007032888

  • Amperage - 15 Amp

  • Catalog Number - 26252CD

  • Color - Brown

  • Country of Origin - Mexico

Packaging

  • 1 ea

EAN

00785007032888

Part #

180063

Catalog #

26252-CD

Commercial reference

26252-CD

12-Digit UPC:

785007032888

Amperage:

15 Amp

Catalog Number:

26252CD

Color:

Brown

Country of Origin:

Mexico

Depths:

0.78 Inch

ERP_productname:

PASS 26252-CD 15A DUAL CONT DECO RECP BR

Family Brand Name:

Pass & Seymour

Grade:

Specification

Heights:

2.635 Inch

NEMA:

5-15R

Sub Brand:

Pass & Seymour

Type:

Decorator

Voltage:

125 Volt

Widths:

1.322 in

SoneparProductId:

SKU_US_73012536

This durable, dependable Plug Load receptacle is designed to help you meet ASHRAE energy standards. The controlled marking printed on the tough nylon face is both NEMA-approved and compliant with the National Electrical Code. Features: NEMA approved controlled receptacle marking pad printed on the face of receptacle for superior abrasion resistance.; CH versions feature a factory broken split circuit tab allowing you to control half of the receptacle.; Can be used to control loads using the Wattstopper DLM system and other building control systems.; Corrosion-resistant, plated steel strap locked into assembly to prohibit strap from bending away from body.; One-piece, brass, triple-wipe power contacts for lasting retention.; Heavy-duty compact design for easier installation and long lasting performance.; Impact-resistant nylon face.; Terminal compartments isolated from each other for positive conductor containment.; Side and internal screw-pressure-plate back wire accepts #14 - #10 AWG solid or stranded wire.; All devices fit standard #26 opening wall plate.; Tri-drive terminal and mounting screws.; Auto-ground clip assures positive ground.; For covering patents, see www.legrand.us/patents.; For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here. - Certifications: cULus Listed
