Pass & Seymour / Legrand - Pass & Seymour HSWF3W 6A Fan Control Humidity Sensor - White

CopyCopy

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 785007057393

  • Amperage - 6 Amp

  • Applications - Residential

  • Catalog Number - HSWF3W

  • Coil Voltage - 120 V

Packaging

  • 1 ea

EAN

00785007057393

Part #

171142

Catalog #

HSWF3W

Commercial reference

HSWF3W

12-Digit UPC:

785007057393

Amperage:

6 Amp

Applications:

Residential

Catalog Number:

HSWF3W

Coil Voltage:

120 V

Color:

White

Country of Origin:

China

ERP_productname:

PASS HSWF3W HUMIDITY SENSOR FAN ONLY 120V 3A MAX WH

Family Brand Name:

Pass & Seymour

Finish:

Matte

Mounting Type:

Surface

Number of Poles:

1 Pole

Size:

1.26" Depth x 1.77" Width x 3.281" Height

Sub Brand:

Pass & Seymour

Tc Connection:

Back & Side Wired

Type:

Back and Side Wired

Voltage:

120 VAC

Wattage:

Fluorescent: 400 Watt Incandescent: 600 Watt LED/CFL: 150 Watt

Wire Size:

14-12 AWG

SoneparProductId:

SKU_US_27111575

Humidity Based Fan Control, HSW, adds intelligent moisture detection to any fan or ventilation system. HSW senses condensation levels in the air, turns on the fan or ventilation system, and runs it until the room is back to a safe moisture level. HSW has adjustable timer settings for manual time use and adjustable condensation for sensitivity. The capability to adjust the sensitivity level on HSW enables the end user to truly tailor their fan or ventilation system to any environment regardless of room size, climate or season. Features: Turns ON the fan when condensation is present and OFF when dry.; Adjusts sensors to solve moisture problems.; Helps fight mold.; Ultra moisture-sensing adaptive technology (patented).; Manual timer settings from 5-60 minutes.; Great for tenant and family use.; Manual fan control for immediate ventilation.; Manual bathroom lighting control (HSWC only).; Lets you know the fan is ON.; Tamper-proof settings cover. - Certifications: cULus Listed
