Pass & Seymour / Legrand - Pass & Seymour PTTR62-W PlugTail™ Industrial Extra Heavy-Duty Spec Grade Tamper-Resistant Duplex Receptacle, 15A 125V - White

CopyCopy

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 785007860276

  • Amperage - 15 Amp

  • Applications - Commercial

  • Catalog Number - PTTR62W

  • Color - White

Packaging

  • 1 ea

EAN

00785007860276

Part #

194669

Catalog #

PTTR62-W

Commercial reference

PTTR62-W

12-Digit UPC:

785007860276

Amperage:

15 Amp

Applications:

Commercial

Catalog Number:

PTTR62W

Color:

White

Conductor Size:

14-10 AWG

Country of Origin:

Mexico

Depths:

0.866 Inch

ERP_productname:

PASS PTTR62-W TAMPER RESIS EHD 15A/125V WH

Family Brand Name:

Legrand

Grade:

Industrial

Heights:

2-3/4 Inch

Material:

Thermoplastic

NEMA:

5-15R

Number of Phases:

3 Phase

Number of Poles:

2 Pole

Number of Wires:

3 Wire

Size:

5.13x2x1.4

Sub Brand:

Pass & Seymour

Type:

Non-Reversing

Voltage:

125 Volt

Widths:

1.625 in

Wire Size:

10 AWG

SoneparProductId:

SKU_US_72329640

PlugTail® Industrial Extra Heavy-Duty Spec Grade Tamper-Resistant Duplex Receptacle 15 A 125 V WhiteFor detailed PlugTail® information, visit our PlugTail® Headquarters. For detailed Tamper-Resistant receptacle information, visit our Tamper-Resistant Receptacles page. Features: .036 inch thick, brass, triple-wipe power contacts for lasting retention.; Extra heavy-duty 0.050'' thick brass mounting strap for superior performance and durability.; No exposed terminals create a finger safe application before, during, and after installation.; Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections.; Crimped and welded contacts.; Ultrasonically welded polycarbonate connector housing secures terminations and conductors in a UL Listed, finger safe housing.; Large brass contacts snugly terminate on device blade terminals.; Pre-stripped connector leads fasten to conductors, easier than standard pigtails.; Auto-ground clip assures positive ground.; For covering patents, see www.legrand.us/patents.; For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here. - Certifications: Federal Spec Listed; cULus Listed
