Pass & Seymour / Legrand - Pass & Seymour TR26361-W 20 Amp 125 VAC 2-Pole 3-Wire NEMA 5-20R White Nylon Face Tamper-Resistant Single Receptacle

CopyCopy

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 785007005004

  • Amperage - 20 Amp

  • Applications - Commercial Volt Applications

  • Catalog Number - TR26361W

  • Color - White

Packaging

  • 1 ea

EAN

00785007005004

Part #

222688

Catalog #

TR26361-W

Commercial reference

TR26361-W

12-Digit UPC:

785007005004

Amperage:

20 Amp

Applications:

Commercial Volt Applications

Catalog Number:

TR26361W

Color:

White

Conductor Size:

14-10 AWG

Country of Origin:

Mexico

Depths:

1.188 Inch

ERP_productname:

PASS TR26361-W DECO REC SGL TAMPER RES 20A/125V WH

Family Brand Name:

Pass & Seymour

Finish:

Matte

Grade:

Federal Specification

Heights:

2.635 Inch

Material:

Nylon

NEMA:

5-20R

Number of Poles:

2 Pole

Number of Wires:

3 Wire

Size:

1.322 in L x 1.188 in W x 3.813 in H

Sub Brand:

Pass & Seymour

Tc Connection:

Back and side wire

Type:

Single Receptacles

Voltage:

125 Volt

Widths:

1.322 in

Wire Size:

10 AWG

SoneparProductId:

SKU_US_58178298

Tamper-Resistant Heavy-Duty Decorator Spec Grade Single Receptacle, Back and Side Wire, 20A, 125V Features: Dual mechanical shutter system to help prevent insertion of foreign objects.; Two drive screws anchor strap to back body and face where abrupt removal torque is greatest.; Easily accessed break-off line-contact connecting tab for fast and easy split-circuit wiring.; Backed-out tri-drive brass terminal screws for faster installation.; Internal screw-pressure-plate back and side wire capability.; Two back wire holes for additional wiring flexibility.; .032 inch thick brass triple-wipe power contacts.; Two drive screws anchor steel strap to back body and face where abrupt removal torque is greatest.; For covering patents, see www.legrand.us/patents.; Temperature Rise: Maximum 30±C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60±C, minimum -40±C without impact - Certifications: cULus Listed
