Phoenix Blocks - PHNX 1803426 MCV 1 5/ 2-G-3 81

PCB headers, nominal cross section: 1.5 mm., color: green, nominal current: 8 A, rated voltage (III/2): 160 V, contact surface: Tin, type of contact: Male connector, number of potentials: 2, number of rows: 1, number of positions: 2, number of connections: 2, product range: MCV 1,5/..-G, pitch: 3.81 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.4 mm, number of solder pins per potential: 1, plug-in system: COMBICON MC 1,5, Pin connector pattern alignment: Standard, locking: without, mounting: without, type of packaging: packed in cardboard Features: Well-known mounting principle allows worldwide use; Vertical connection enables multi-row arrangement on the PCB; Maximum flexibility when it comes to device design . one header for connectors with different connection technologies - Approvals: VDE Gutachten mit Fertigungs.berwachung; EAC; IECEE CB Scheme; CSA; cULus Recognized
