Phoenix Blocks - PHNX 1804904 PC 4/ 2-ST-7 62

PCB connector, nominal cross section: 4 mm., color: green, nominal current: 20 A, rated voltage (III/2): 630 V, contact surface: Tin, type of contact: Female connector, number of potentials: 2, number of rows: 1, number of positions: 2, number of connections: 2, product range: PC 4/..-ST, pitch: 7.62 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, conductor/PCB connection direction: 0 ., locking clip: - Locking clip, plug-in system: COMBICON PC 4, locking: without, mounting: without, type of packaging: packed in cardboard Features: Well-known connection principle allows worldwide use; Low temperature rise, thanks to maximum contact force; Allows connection of two conductors; Integrated double steel spring provides additional safety in the event of temperature and power fluctuations - Approvals: BV; EAC; RS; CSA; cULus Recognized
