Phoenix Blocks - PHNX 1823638 SPT-THR 1 5/ 2-H-3 5 P20 R24

PCB terminal block, nominal current: 13.5 A, rated voltage (III/2): 160 V, nominal cross section: 1.5 mm., number of potentials: 2, number of rows: 1, number of positions per row: 2, product range: SPT 1,5/..-H-THR, pitch: 3.5 mm, connection method: Push-in spring connection, mounting: THR soldering, conductor/PCB connection direction: 0 ., color: black, Pin layout: Linear double pinning, Solder pin [P]: 2 mm, number of solder pins per potential: 2, type of packaging: 24 mm wide tape Features: Time saving push-in connection, tools not required; Defined contact force ensures that contact remains stable over the long term; Intuitive use through colour coded actuation lever; Designed for integration into the SMT soldering process; Quick and convenient testing using integrated test option; Operation and conductor connection from one direction enable integration into front of device; Two solder pins reduce the mechanical strain on the soldering spots - Approvals: VDE Zeichengenehmigung; EAC; IECEE CB Scheme; cULus Recognized
