Phoenix Blocks - PHNX 1825527 IC 2 5/ 4-STGF-5 08

PCB connector, nominal cross section: 2.5 mm., color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: Tin, type of contact: Male connector, number of potentials: 4, number of rows: 1, number of positions: 4, number of connections: 4, product range: IC 2,5/..-STGF, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, conductor/PCB connection direction: 0 ., locking clip: - without locking clip, plug-in system: COMBICON MSTB 2,5, locking: Screw locking, mounting: Threaded flange, type of packaging: packed in cardboard Features: Plug with inverted contact system (pin contact); Well-known connection principle allows worldwide use; Easy PCB replacement thanks to plug-in modules; Screwable flange for superior mechanical stability; Inverted connector with pin contacts for touch-proof device outputs or free-hanging cable/cable connections; Can be combined with the MSTB 2,5 range; Low temperature rise, thanks to maximum contact force - Approvals: VDE Zeichengenehmigung; EAC; IECEE CB Scheme; CSA; cULus Recognized
