Phoenix Blocks - PHNX 1934861 PT 1 5/ 2-PVH-5 0

PCB connector, nominal cross section: 1.5 mm., color: green, nominal current: 12 A, rated voltage (III/2): 400 V, contact surface: Tin, type of contact: Female connector, number of potentials: 2, number of rows: 1, number of positions: 2, number of connections: 2, product range: PT 1,5/..-PVH, pitch: 5 mm, connection method: Screw connection with wire protector, screw head form: H1L Philipps recess with slotted Torx, conductor/PCB connection direction: 0 ., plug-in system: COMBICON PST 1,3, locking: without, mounting: without, type of packaging: packed in cardboard Features: Well-known connection principle allows worldwide use; Low temperature rise, thanks to maximum contact force; High terminal block capacity thanks to rectangular terminal block space; Allows connection of two conductors; Horizontal and vertical connection option for optimum conductor routing; The latching on the side enables various numbers of positions to be combined - Approvals: EAC; SEV; IECEE CB Scheme; cULus Recognized
