Phoenix Blocks - PHNX 1985315 PTSA 1 5/14-3 5-Z

PCB terminal block, nominal current: 8 A, rated voltage (III/2): 400 V, nominal cross section: 1.5 mm., number of potentials: 14, number of rows: 1, number of positions per row: 14, product range: PTSA 1,5, pitch: 3.5 mm, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 45 ., color: green, Pin layout: Zigzag pinning W, Solder pin [P]: 3.5 mm, number of solder pins per potential: 1, type of packaging: packed in cardboard. Offset soldering legs, two-rowed Features: Time saving push-in connection, tools not required; Defined contact force ensures that contact remains stable over the long term; Angled connection enables multi-row arrangement on the PCB - Approvals: VDE Gutachten mit Fertigungs.berwachung; EAC; CCA; cULus Recognized
