Phoenix Blocks - PHNX 2862822 IB IL 24 DO 32/HD-PAC
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 179189076172
Catalog Number - 2862822
Country of Origin - Germany
Depths - 71.5 mm
ERP_productname - PHNX 2862822 IB IL 24 DO 32/HD-PAC
Packaging
1 ea
EAN
Part #
167006
Catalog #
2862822
Commercial reference
2862822
12-Digit UPC:
179189076172
Catalog Number:
2862822
Country of Origin:
Germany
Depths:
71.5 mm
ERP_productname:
PHNX 2862822 IB IL 24 DO 32/HD-PAC
Family Brand Name:
Phoenix Products
Heights:
119.8 mm
Output Voltage:
24 V
Widths:
48.8 mm
SoneparProductId:
SKU_US_73206596
Inline, Digital output terminal, Digital outputs: 32, 24 V DC, 500 mA, connection technology: 1-conductor, transmission speed in the local bus: 500 kbps, degree of protection: IP20, including Inline connectors and marking fields Features: 32 digital outputs; Connection of actuators in single-wire technology; Nominal current per output: 500 mA; Total current of the terminal: 8 A; Short-circuit-proof and overload-protected outputs - Approvals: BV; EAC; ATEX; BSH; LR; DNV GL; ABS; UL Listed; cUL Listed; UL Recognized; cUL Recognized
