Phoenix Blocks - PHNX 2905228 TYPE SURGE SUPRESSOR DISCONTINUED REPLACED BY 2907918
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 463569396906
Catalog Number - 2905228
Depths - 7.5 mm
ERP_productname - PHNX 2905228 TYPE SURGE SUPRESSOR DISCONTINUED REPLACED BY 2907918
Family Brand Name - Phoenix Products
Packaging
1 ea
EAN
Part #
116086
Catalog #
2905228
Commercial reference
2905228
12-Digit UPC:
463569396906
Catalog Number:
2905228
Depths:
7.5 mm
ERP_productname:
PHNX 2905228 TYPE SURGE SUPRESSOR DISCONTINUED REPLACED BY 2907918
Family Brand Name:
Phoenix Products
Heights:
90 mm
Widths:
17.7 mm
SoneparProductId:
SKU_US_58642844
Pluggable device protection, according to type 3/class III, for 1-phase power supply networks with separate N and PE (3-conductor system: L1, N, PE), with integrated surge-proof fuse and remote indication contact. Also suitable for DC applications. Features: Varistor-based device protection; Can be used without separate backup fuse thanks to integrated overcurrent protection; For 1-phase power supply units (AC/DC); Pluggable; Optical status indicator via LED; With floating remote indication contact; Plugs can be checked with CHECKMASTER 2 - Approvals: CCA; EAC; GL; KEMA-KEUR; CSA; UL Recognized
