Raco Manufacturing - Raco 509 3" x 2" Steel Switch Box, 2-1/2" Deep, Gangable, 1/2" End Knockouts, Old Work Clips
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 050169005095
Applications - Electrical
Catalog Number - 509
Color - Gray
Construction - Gangable
Packaging
1 ea
EAN
00050169005095
Part #
208417
Catalog #
509
Commercial reference
509
12-Digit UPC:
050169005095
Applications:
Electrical
Catalog Number:
509
Color:
Gray
Construction:
Gangable
Country of Origin:
China
Depths:
2-1/2 Inch
ERP_productname:
RACO 509 2-1/2 DEEP SW BOX OLD WORK EARS 1/2 KO
Family Brand Name:
RACO
Heights:
4.219 Inch
Length:
2-1/2 Inch
Material:
Steel
Number of Gangs:
1 Gang
Size:
2-1/2 IN
Type:
3 IN x 2 IN switch box
Widths:
2.625 in
SoneparProductId:
SKU_US_57812886
3 in. x 2 in. Switch Box, Gangable, 2-1/2 in. Deep, Four 1/2 in. KO's, Plaster Ears, Old Work Features: 3 in. x 2 in., 2-1/2 in. deep; Gangable switch boxes offer the option of constructing a box to hold two or more devices; With proper fitting can be used for conduit, NMSC, armored, metal clad, flex cable; Supplied with four 1/2 in. knockouts; Includes plaster ears and clips for \"cut-in\" or \"old work\" applications; 12.5 cu. in. capacity; Acceptable for use in 2-hour fire rated walls - Prop 65: No
