Siemens - Siemens E1FFD63B200 BREAKER ENC1F 3P 20
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 783643293229
Catalog Number - E1FFD63B200
ERP_productname - SIEM E1FFD63B200 BREAKER ENC1F 3P 200A 600V 22KA
Enclosure - TYPE 1F
Family Brand Name - Siemens
Packaging
1 ea
EAN
00783643293229
Part #
434966
Catalog #
E1FFD63B200
Commercial reference
E1FFD63B200
12-Digit UPC:
783643293229
Catalog Number:
E1FFD63B200
ERP_productname:
SIEM E1FFD63B200 BREAKER ENC1F 3P 200A 600V 22KA
Enclosure:
TYPE 1F
Family Brand Name:
Siemens
Frame:
FD
Heights:
7 Inch
Interrupt Rating:
22 kAIC
Length:
40 Inch
Number of Poles:
3 Pole
Sub Brand:
SENTRON
Trip Type:
THERMAL MAGNETIC
Type:
FD6
Voltage:
600 Volt
Widths:
13 in
SoneparProductId:
SKU_US_193641609
SIEMENS LOW VOLTAGE ENCLOSED SENTRON MOLDED CASE CIRCUIT BREAKER (ASSEMBLED) WITH THERMAL - MAGNETIC TRIP UNIT. 200A 3-POLE 600V STANDARD 40 DEG C BREAKER FD FRAME WITH STANDARD BREAKING CAPACITY (FD63B200). INTERCHANGEABLE TRIP UNIT. NEMATYPE 1 ENLCOSURE FLUSH MOUNTED (F6N1F). ORDER NEUTRAL (N250). INCLUDES LINE ANDLOAD SIDE LUGS (TA1FD350A) WIRE RANGE 6AWG - 350KCMIL (CU) / 4AWG - 350KCMIL (AL). ENCLOSURE DIMENSIONS (W x H x D) IN 11.47 x 38.41 x 5.06.
