Siemens - Siemens HGG3B015L HGG MCCB, 600/
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 887621278700
Amperage - 15 Amp
Applications - INDUSTRIAL
Catalog Number - HGG3B015L
Current - 15 Amp
Packaging
1 ea
EAN
00887621278700
Part #
349426
Catalog #
HGG3B015L
Commercial reference
HGG3B015L
12-Digit UPC:
887621278700
Amperage:
15 Amp
Applications:
INDUSTRIAL
Catalog Number:
HGG3B015L
Current:
15 Amp
ERP_productname:
SIEM HGG3B015L BRKR HGG 15A 3P 480V 35K LUGS
Family Brand Name:
Siemens Canada
Frame:
125A
Interrupt Rating:
35 kAIC
Material:
MOLDED CASE CIRCUIT BREAKER
Number of Poles:
3 Pole
Sub Brand:
Molded Case Circuit Breakers
Tc Connection:
CABLE IN-CABLE OUT
Trip Type:
THERMAL MAGNETIC TRIP UNIT
Type:
HGG
Voltage:
480 Volt
SoneparProductId:
SKU_US_75328533
SIEMENS LOW VOLTAGE G FRAME CIRCUIT BREAKER WITH THERMAL - MAGNETIC TRIP. UL LISTED HGG FRAME WITH HIGH BREAKING CAPACITY. 15A 3-POLE (14KAIC AT 600Y/347V) (35KAIC AT 480V). SPECIAL FEATURES MOUNTS ON DIN RAIL / SCREW, LINE AND LOAD SIDE LUGS (TC1Q1) WIRE RANGE 14 - 10 AWS (CU/AL). DIMENSIONS (W x H x D) IN 3 x 5.4 x 2.8.
