Siemens - Siemens TPS3B0910D00 SPD1 09 EXT 120/24
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 040892249842
Applications - MOUNTSTOELECTRICALDISTRIBUTIONEQUIPMENT
Catalog Number - TPS3B0910D00
ERP_productname - SIEM TPS3B0910D00 SPD1 09 EXT 120/240V 100KA DRY
Family Brand Name - Siemens
Packaging
1 ea
EAN
00040892249842
Part #
380950
Catalog #
TPS3B0910D00
Commercial reference
TPS3B0910D00
12-Digit UPC:
040892249842
Applications:
MOUNTSTOELECTRICALDISTRIBUTIONEQUIPMENT
Catalog Number:
TPS3B0910D00
ERP_productname:
SIEM TPS3B0910D00 SPD1 09 EXT 120/240V 100KA DRY
Family Brand Name:
Siemens
Material:
Polycarbonate
Number of Phases:
3 Phase
Sub Brand:
TPS309
Tc Connection:
WIRELEADS
Type:
100kASURGE
Voltage:
120 Volt
SoneparProductId:
SKU_US_73354188
Siemens Low Voltage s Surge Protection Devices Line of TPS309 as part of the External (Remote Mounted) Group. Type 1 SPD. Dimensions (L x W x H) 8.3 x 3.6 x 3.0. 3-Phase 4-Wire Rated 120/240 V surge current 100 kA per phase. Special features dry contact and auible alarm, mounts internal to P1 panelboards and busway
