Square-D / Schneider - SQD 8501KFDR12V53 RELAY 1CO QC PINS
Login or create an account to check prices & order
Essential specifications
12-Digit UPC - 785901984412
Applications - 1 HP 277 V AC
Catalog Number - 8501KFDR12V53
Country of Origin - China
Depths - 1.4 Inch
Packaging
1 ea
EAN
00785901984412
Part #
122203
Catalog #
8501KFDR12V53
Commercial reference
8501KFDR12V53
12-Digit UPC:
785901984412
Applications:
1 HP 277 V AC
Catalog Number:
8501KFDR12V53
Country of Origin:
China
Depths:
1.4 Inch
ERP_productname:
SQD 8501KFDR12V53 RELAY 1CO QC PINS 10A@240V 24VDC COIL FL
Family Brand Name:
Square D
Heights:
2-3/4 Inch
Mounting Type:
Flange
Type:
DPDT,GENERAL PURPOSE,RELAY
Widths:
1.4 in
SoneparProductId:
SKU_US_31935537
8501KF universal relays are designed for multipole switching applications at 300 VAC or lower. These relays are designed to be flange mounted into a panel. This flange mounted relay has DPDT contact arrangements. It has two normally open and two normally closed contacts. The contacts have a 10 ampere rating 277 VAC, a 10 ampere rating at 28 VDC, a 1/3 HP rating at 120 VAC, a 1 HP rating at 277 VAC and a B300 inductive rating. Relays can be ordered with a wide variety of coil voltages. This relay has a 24 VDC nonreplaceable coil. A green LED indicator is supplied on this relay. 8501KF relays are UL component recognized and CSA certified.
