Square-D / Schneider - SQD HGA36150U33X Circuit breaker, P

CopyCopy

Login or create an account to check prices & order

Essential specifications

  • 12-Digit UPC - 785901947714

  • Amperage - 150 Amp

  • Catalog Number - HGA36150U33X

  • Color - Black

  • Country of Origin - Canada

Packaging

  • 1 ea

EAN

00785901947714

Part #

412016

Catalog #

HGA36150U33X

Commercial reference

HGA36150U33X

12-Digit UPC:

785901947714

Amperage:

150 Amp

Catalog Number:

HGA36150U33X

Color:

Black

Country of Origin:

Canada

Depths:

86 mm

ERP_productname:

SQD HGA36150U33X CIRCUIT BREAKER, POWERPACT H, 150A, 3 POLE, 600VAC, 18KA, I-LINE, MICROLOGIC 3.2S, 80%, ABC

Family Brand Name:

Square D

Frame:

G

Heights:

4-1/2 Inch

Interrupt Rating:

18, 35, 65 kAIC

Length:

16 mm

Mounting Type:

I-Line Bracket)

Number of Poles:

3 Pole

Tc Connection:

AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD

Trip Type:

ELECTRONIC, STANDARD, MICROLOGIC 3.2 S, LSI

Type:

CIRCUIT BREAKER

Voltage:

600 Volt

Widths:

104 mm

SoneparProductId:

SKU_US_31266479

PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides Micrologic Standard with a 3.2S trip unit and an LSI function with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 150A, 3 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an ABC phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked. Prop 65: WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov - Compatible Products: VTRIPHJ
